Chassis en aluminium E50

Performance

Air Permeability: up to Class 4

Watertightness: up to Class E1200

Resistance to wind load: up to Class C3

Thermal transmittance (Uf): from 2.0 W/(m2K)

Acoustic performance: up to 41 dB

Techniques

One frame, all around Narrow Interlock concept

Optimum design for reduced weight

Single,double and triple glazing optionup to 40 mm

Energy efficiency concepts: Advanced, Improved & Basic

Hardware

Slide / Lift & Slide mechanism

Max. sash weight (for Slide mechanism): 200 kg

Max. sash weight (for Lift & Slide mechanism): 300 kg

On demand: Max. sash width/ height up to 3300 mm/3300 mm

On demand: up to 400kg ( for Lift & Slide mechanism)

Surface treatment options

RAL colours

ETEM colours

Anodising

Wood effects

Quality Standards: QUALICOAT | QUALANOD | QUALIDECO
